How to test factory settings (with positioner)
Using the manual override, drive the actuator in the clockwise
direction to the end position.
According to the situation:
• If the end position cam trips the switch at the same time
as the valve is closed, you do not need to resume the
settings.
• If the end position cam trips the switch before the valve
is closed, set the cam slightly counterclockwise to get
the switch tripped and the valve closed at the same time
• If the valve is closed before the cam is tripped, set the
cam slightly clockwise to get the switch tripped and the
valve closed at the same time
If it is wired and if necessary, set the clockwise signaling cam
accordingly.
Using the manual override, drive the actuator counterclockwise
to the end position.
Proceed to the same checks as in step 2 with the opposite
directions.
If it is wired and if necessary, set the counterclockwise signaling
cam accordingly.
