CARE OF YOUR MACHINE
Cleaning the Hook Race and Feed Dog
WARNING:
Turn the power switch off and unplug the machin before
cleaning.
The machine must only be disassembled as described in
this section.
CAUTION:
Do not store the machine in a high-humidity area, near a
heat radiator, or in direct sunlight.
Installing the Bobbin Holder
Insert the bobbin holder so that the knob fits next to
the stopper in the hook race.
Insert the bobbin.
Attach the stitch plate with the setscrews . After cleaning
the machine, make sure the needle and presser foot are
attached.
Bobbin holder
Stopper
Knob
T screwdriver
Setscrews
Press the needle stop up/down button to raise the needle. Turn
off the power switch.
Remove the needle and presser foot.
Remove the cover plate by sliding the cover plate release button
to the right. Take out the bobbin. Brush out dust and lint. (You
may also use a vacuum cleaner.)
Remove the setscrew out of the stitch plate . Use the
T-screwdriver supplied with the machine. Remove the
stitch plate .
Lift up the bobbin holder and remove it.
Clean the bobbin holder with a lint brush .
Clean the feed dog and hook race with the lint brush.
Clean the center of the hook race with a dry cloth.
T screwdriver
Setscrews
Stitch plate
Lint brush
Bobbin holder
Feed dog
Hook race
* The machine does not require oiling.
PLEASE NOTE:
Clean the outside of the machine with a soft cloth and
soap. After cleaning the machine, make sure the needle
and presser foot are attached.
