Bernini Be242 - Dimensions & Connections

Be242 Be242RB Be242-22 OEM's Manual V4.X.XX - March - 2023 page 25
25
19.0 Dimensions & Connections
JA 6-Poles 5mm
JD 8-Poles 5mm
JE 4-Poles 5mm
JF 4-Poles 7.5mm
1
Alternator Excitement
9
Low Fuel Input
18
Current Trasf. 1
L1
Generator
Volatge
Input
2
Fuel Solenoid
10
Input 3
19
Current Trasf. 2
L2
3
Start Solenoid
11
Low Oil Pressure
20
Current Trasf. 3
L3
4
Stop Solenoid
12
High Temperature
21
Common CTs
KG
Conatct Output
5
Output 2
13
Input 2
JC SUB-D 25
POLES
(cable 1m included
in the Be242 kit)
JG 4-Poles 7.5mm
6
Output 1
14
Input 4
R
Mains
Voltage
Input
JB Male Faston 6.3mm
15
Running Plus
S
7
Battery Plus
16
Running Minus
T
8
Battery Minus
KM
Contact Output
BE242RB DIMENSIONS
BE242 DIMENSIONS (DOWNLOAD FOOT PRINT FOR MAKING HOLES)
