Section 4.0 Display messages and LOG Events
The Be242 displays alarms (table 4.10) and messages (table 4.20). The presence of alarms is indicated by the
blinking message [ ALAr.]. Push the [→F9] push buttons to display the alarms one by one. Push the [←F8] push
button to display additional information (section 8.0).
Table 4.10: Alarm messages
Display
Message
Description of the Alarm
Display
Message
Description of the Alarm
[Er.01]
Over Frequency Shutdown (see [P.12])
[Er. 14]
Low Oil Pressure Shutdown
(Pressure switch connected to input #35)
[Er.02]
Engine Belt Break Shutdown (see [P.26])
[Er. 15]
Temperature Switch Shutdown
(Temperature switch connected to Input #34)
[Er.03]
Remote LOCK Shutdown (see 7.07 option
[13])
[Hi-C]
Over Current Shutdown or Warning (see
[P.13]).
[Er.04]
Alternator Failure Shutdown
[Hi-U]
Over Voltage Shutdown (see [P.10])
[Er.05]
Overload Warning (see 7.07 option [20])
[Lo-U]
Under Voltage Shutdown (see [P.09])
[Er.05]
Overload Shutdown (see 7.07 option [21])
[InP.2]
Input 2 Shutdown / Warning (see 7.07)
[Er.06]
Under Frequency Shutdown (see [P.11])
[Er.07]
Fail To STOP Shutdown (see parameter
P.34, section 7, table 7.04)
[InP.3]
Input 3 Shutdown / Warning (see 7.07)
[Er.08]
Emergency Shutdown (see parameter
P.35, section 7, table 7.04)
[InP.4]
Input 4 Shutdown / Warning (see 7.07)
[Er.09]
Emergency Shutdown triggered by Front
Panel (Stop or [0] push button)
[FUEL]
Low Fuel level warning
[Er.10]
Maintenance SERVICE warning
(see parameters P44,P45 and P46)
[rEnt]
The rental contract is going to expire (48
hours remaining). Push [←F8] to display the
value.
[Er.11]
Fail To START Shutdown
[FAIL]
There is an internal failure or memory error in
the BE242 controller (see 12.3)
[Er.12]
Low Fuel Shutdown
[Er. 13]
Battery Voltage Alarm. Push [←F8] to display
the value. (allowed battery limits: 11,8V-
15,5V & 23,6V-31V). Under 7,5V, the Be242
controller will not work.
4.20 Miscellaneous messages & description
[rESt]
The Be242 is counting the rest time between
the starting attempts
[ProG]
The Be242 is in program mode
[n-on]
The MAINS is simulated by an input
programmed with the option [15] (see table
7.07).
[. . . .]
The Be242 is cranking the engine
[ ' ' ' ' ]
The Be242 is performing the pre-glow (P22)
[tEst]
The Be242 is in Test mode
[StoP]
The Be242 is stopping the engine (P25)
[ - - - - ]
Measurement out of range or disabled
[U-uP]
Warm-up time of the engine before closing the
contactor of the generator (P23).
[CooL]
The engine is running offload for
cooling.
[ dEL]
The delay time before cranking (P.19, table
7.03A)
