14
2.3. HANDWASH TANK - RINSING TANK
HANDWASH TANK
For hygiene and convenience: a 16-litres water tank (2), independent from the main tank (3), can be used; for
washing hands and body parts (face, eyes, ...) in the event that product is sprayed or splashed on operating
personnel.
The handwash tank is integrated at the rinsing tank (5). Its tap (4) is easily accessible on the front left-hand
side. Washing, by opening the tap (4) more or less according to the required fl ow rate.
RINSING TANK
The fresh water rinsing tank (5) (60, 100 or 200 litres) is located on the front of the main tank (3).
CAUTION: It is ESSENTIAL that the rinsing tank (5) and the handwash tank (2) are fi lled
with clear water, without any pressure, through the lids (1).
4
3
2
5
1
