Berthoud WIN'AIR 600 - WINAIR Circuit with Incorporation Option

40
5.4. SPRAYING CIRCUIT
SERIES WIN'AIR
+ INCORPORATION OPTION
DESCRIPTION OF ITEMS on page 41
1 - Handwash tank (capacity 16 litres).
2 - Main tank (capacity 600, 800, 1,000 or 1,500 litres).
3 - Tank rinsing.
4 - Float gauge.
5 - Delivery fi lter.
6 - Spraying pressure gauge.
7 - Electric fl ap valves (V.E.C.).
8 - Mixing hydro-injector.
9 - Drain valve.
10 - Regulating valve.
11 - Collector.
12 - Optional valve.
13 - Mixing valve.
14 - Spraying valve.
15 - Suction valve.
16 - Suction fi lter.
17 - Pump APS 61 (APS 96 optional).
18 - Rinsing tank (capacity 60, 100 or 200 litres).
