32
4.8. LUBRICATION AND GREASING
• Pump:
- Every 50 hours, check the oil level which should reach the mark shown on the transparent volume
compensator (1) (fi g. 38) of the pump and top up if required.
- Every 200 hours, drain the pump and fill with oil up to the level of the transparent volume
compensator (1) (fi g. 38).
• Transmission:
- Lubricate the tubes and PTO joints (take down the lower cap).
- See manufacturer’s documentation.
• Wheel stub axle:
- Every 200 hours, grease the wheel stub axles.
• Clutch:
- Grease the ventilation locking clutch.
• Hydraulic version of Raising / Lowering:
- Grease the raising / lowering slideway of the arch (nipples (G) (fi g. 39)).
We recommend:
- SAE 30 special high pressure oil, 2-litre can, BERTHOUD reference 769.286.
- Grease MOBILUX EP2 or ELF EPEXA 2.
39
G
38
1
