1
GENERAL INFORMATION
11
GB
1
2
3
4
5
6
A
GEARCHANGE LEVER
Gearchange lever A is fi tted to the left side
of the engine.
The positions corresponding to the different
gears are shown in the fi gure.
BRAKE PEDAL
Brake pedal 9 is located in front of the
right-hand footrest.
9
KICKSTART
The kick-starter pedal 10 is located on the
right side of the engine. The upper part is
rotatable. To start, depress the kick-starter
outward and with a quick movement down-
ward. The pedal will automatically return
upwards. After starting, manually fold the
pedal in the rest position.
10
