4
ADJUSTMENTS
43
GB
ADJUSTING THE FORK
The hydraulic rebound damper determines
the behaviour of the telescopic fork during
extension and can be adjusted by means
of screw 1. Turning the screw clockwise
increases the action of the rebound dam-
per; turning it anticlockwise decreases the
action of the rebound damper.
For standard calibration, refer to page
20.
ADJUSTING THE SPRING PRELOAD
(FACTORY)
Spring preload is adjusted by means of
screw 2. Turning clockwise will increase
the preload, while rotating counter-
clockwise decreases the preload.
For standard calibration, refer to page
20.
1
2
