Motor Chain Adjustment
( Note: Always unplug machine when performing service to machine)
Procedure
1. Remove water bottle and water tank assembly
2. Remove the left side cover
3. Loosen the 2 nuts that hold the motor onto the motor bracket
(Be sure not to remove the nut completely)
4. Push the motor towards the rear of the bracket until there is no
more slack on the motor chain
5. Tighten the nuts on the motor chain bracket until snug. Do not
over tighten
6. Replace cover, tank and water bottle.
Loosen nuts behind bracket
To adjust
