Better Packages Inc. 20
Tape Sensor
(Note: Always unplug machine when performing service to machine)
Procedure
1. Remove left side cover
2. Remove sensor from back of heater assembly and remove connector
from board
3. Replace sensor onto the back of the heater assembly
4. Replace connector back onto board
5. And fasten with a cable tie
6. Replace cover back onto machine
PUSH OUT
