Better Packages Inc. 22
Fuses
(Note: Always unplug machine when performing service on machine)
There are 2 fuses in this machine.1 is on the control board and 1 is in the connector plate
Procedure
1. To change the fuse in the connector plate unscrew fuse holder on the
plate above where the machine is plugged in.
2. Remove the fuse and replace with a new one (pn 2341)
3. To change the fuse on the board remove the left side cover.
4. The fuse is located below the transformer. Remove the fuse and replace
with a new one(pn2128)
5. Replace the left cover back onto machine
fuses
