44
Isssue 2
Doc. No. 002 Issue 2 April 1998
TC5000 Port Status
Power supply Safety Extra Low Voltage
(SELV)
TP5/M65 door terminals Safety Extra Low Voltage
(SELV)
DTE connector ( Printer ) Safety Extra Low Voltage
(SELV)
Apartment telephones Safety Extra Low Voltage
( SELV)
PSTN connector Telecommunications Network
Voltage (TNV)
When connecting other equipment to the TC5000 ports, only
circuits having the same safety status should be
interconnected.
The TC5000 is not fitted with a mains isolation switch and
should there fore be installed near to an accessible mains
outlet.
Connecting Line Cords
The line cord supplied with the TC5000 is terminated with a
BT type 431A plug at one end and bare stripped cable at the
other end. To avoid inadvertent contact with the PSTN,
ALWAYS attach the stripped bare end into the terminal
blocks on the TC5000 first BEFORE connecting to the
network.
8. UK STATUTORY INFORMATION
