TG 500 – Synchronisation
26
5. Synchronisation
• The receiver can transfer the frequency and other settings such
as power lock of a particular channel to a transmitter via an
infrared interface.
• To transfer to the transmitter, press the synchronisation button
on the receiver.
• There is an infrared interface in the transmitter’s battery
compartment.
• During synchronisation, hold the infrared interface of the hand-
held transmitter or the beltpack transmitter in the open
battery compartment of the particular switched-on transmitter
directly in front of the infrared interface on the receiver.
Important: If the battery symbol on the transmitter display no
longer shows any bars, this means the batteries are almost flat
and synchronisation should thus not be performed because it
will not be completed or will be terminated.
Synchronising two transmitters to the same channel
• Press and hold the on/off button on the handheld or beltpack
transmitter for around 8 seconds to go into “RF off” mode.
You can now synchronise a spare transmitter to the same
channel, for example, even though the main transmitter is still
active (audio continues to function while synchronising).
• Perform synchronisation for the spare transmitter as described
above.
• To leave “RF off” mode, turn the transmitter off and on again.
Important: Before switching the spare transmitter off and on
again, you must switch off the main transmitter, otherwise there
will be interference on the channel if two transmitters are active
on the same frequency.
Beltpack transmitter
user
800.000
Figure 5-1: Synchronising the transmitter with the receiver
Figure 5-2: Synchronising the handheld transmitter
Figure 5-3: Synchronising the beltpack transmitter
6. Instructions for all transmitters
• Check the charging status of the transmitter battery/batteries
and replace if necessary. Only use new alkaline batteries or
charged rechargeable batteries.
• Switch the transmitter off before replacing the batteries.
• If you do not use the transmitter for weeks or months, please
remove the batteries. Batteries may leak after long periods of
non-use and may corrode circuit paths and components. This
means repairs will no longer be possible. In this case, all
warranty claims will be void. Even the description “Leak proof”
on batteries is not a guarantee against leaks.
• From time to time, clean the battery contacts with a soft cloth
moistened with spirit or alcohol.
• Do not dispose of used batteries in the household waste.
Instead, take them to local collection points.
• To charge the batteries, use standard battery chargers or the
WA-CD charger from beyerdynamic.
