MOD. BEZZERA MODA PM – DE – DE+D – DE+D+M
V380-415/3+N
THREE-PHASE
󻸫󻸰󾖴󻨳
CONNECTION
WITH NEUTRAL
󼚀󻺠󺩫󼓇󾖴󼍟󺨟
V220-240/3
THREE-PHASE
󻸫󻸰󾖴󻃧󼸯
CONNECTION
󼍟󺨟
V220-240/2
SINGLE-PHASE
󻁗󼓫󾖴󼑳󻸰
CONNECTION
󼍟󺨟
V220-240/2
SINGLE-PHASE
󻁗󼓫󾖴󼑳󻸰
CONNECTION
󼍟󺨟
CONNESSIONI ELETTRICHE
ELECTRIC CONNECTION
BRANCHEMENT ELECTRIQUE
STROMANSCHLUSS
CONEXIÓN ELÉCTRICA
电气连接电气连接

󼕳󺮟󾖴󼍟󺨟
(0) Blu (Neutral)
󻮃󻙗󼐟󼚀󼬘󽋋
(0) Blu (Neutral)
󻮃󻙗󼐟󼚀󼬘󽋋
(0) Blu (Neutral)
󻮃󻙗󼐟󼚀󼬘󽋋
(0) Blu (Neutral)
󻮃󻙗󼐟󼚀󼬘󽋋
(0) White (neutral for
USA)
(1) Brown
󺥷󻸸
(1) Brown +(3) Grey
󺥷󻸸󽏻󻸸
(1) Brown +(2) Black
+(3) Grey
󺥷󻸸󺧯󼒯
󽏻󻸸
(1) Brown
󺥷󻸸
(3) Black for USA
(2) Black 󺧯󼒯 (2) Black 󺧯󼒯
(3) Grey 󽏻󻸸
(3P+N+T) (3P+T) (1P+N+T) (1P+N+T)
380-415 Vac; 50-60 Hz 220-240 Vac; 50-60 Hz 220-240 Vac; 50-60 Hz 220-240 Vac; 50-60 Hz
