- 21 -
Control unit
EN
7.1 INVERTER
6.8
J12
RADIO PROGRAMMER CONNECTOR
7. INVERTER CONNECTIONS
CONTROL UNIT
230Vac 50/60Hz with internal protection and fuse.
INVERTER
CONTROL UNIT
INVERTER
7.4
J9
INVERTER SIGNALS
7.2
J2
POWER SUPPLY
7.3 MOTOR
M
CC: Brown
F: Yellow
R: White
B: Gray
A: Pink
GND: Green
COM: Brown
FWD: Yellow
REV: White
N
L
6.6
J8
BOOM LIGHTS CONNECTOR
6.7
J10
EXPANSION CONNECTOR
.
.
.
COM+
GRN
RED
.
.
.
J2
J9
M
FLA
OUT NO CC F
R
S1 S2 P24
FLB FLC CC VI P5 FM
BA
RS 485
GND
COM
FWD
REV
OUT
J9
TCP/IP
SC RS485
ENGLISH
