Bogie block and frame lock BIGAB 8-12 – 14-17
Table 13. Bogie block and frame lock
Pos Description Pos Description
1
Hyd lock 19 H-hose
2
Bolt 20 H-hose
3
Straight nipple 21 H-hose
4
Straight nipple 22 Heat shrink tube
5
Rubber seal 23 Sticker
6
T-nipple 24 Sticker
7
Test point 25 Spiro pipe
8
Hose for manometer 26 Clip double
