BigRep ONE 3 Construction and Function
57
A Control panel (Fig. 3-2)
incl. touch screen
B Z-guide sha s (4 pcs)
C Z-lead spindels (4 pcs)
D Filament guides (2 pcs)
E Print Bed
F Y-guide rails (2 pcs)
G Mobile machine base (4 pcs)
H X-guide rail
I Extruder (2 pcs)
x
y
z
I
B
C
D
E
A
G
F
F
H
Abb. 3-4: Filamentrollenhalter (M)
Fig. 3-2: BigRep ONE
D Filament guide (2 pcs)
K Adjustable roller (2 pcs)
L Adjustable bracket (2 pcs)
M Filament spool holder
N Control cabinet
O Main switch with door lock
P Emergency stop button
R Touchscreen
S USB port
T Reset
M
D
O
N
P
S
R
T
O
K
L
Fig. 3-3: BigRep ONE
Fig. 3-4: Control Panel
Fig. 3-5: Filament spool holder (M)
