BIGTREETECH MANTA E3EZ V1.0 User Manual

Shenzhen Big Tree Technology Co., Ltd.
BIGTREETECH
6 / 30
14. The motor power supply supports up to 56V, and for the larger voltage when using
EZ5160, an isolation chip is used to protect the main control from burning IO.
Specifications
Dimensions
90.8x120mm,
for details please refer to
BIGTREETECH Manta E3EZ
V1.0-SIZE.pdf
Mounting Size
Please refer to
BIGTREETECH Manta E3EZ V1.0-
SIZE.pdf
MCU
ARM Cortex-M0+ STM32G0B1RE 64MHz
Motherboard Power
Supply Voltage
DC12V-DC24V
Motor Power Supply
Voltage
DC12V-DC56V
Logic Voltage
DC 3.3V
Heater Connection
Heated Bed (HB), Heater Cartridge (HE0, HE1)
HB Port Max Current
10A Continuous, 11A Instantaneous
Heater Cartridge Max
Current
5A Continuous, 6A Instantaneous
Fan Port
3 x CNC, 2 x Always On
Fan Port Max Current
1A Continuous, 1.5A Instantaneous
Overall Max
Current(Heater
Cartridge+Driver+All
Fans)
＜
10A
Expansion Port
BLTouch, PS-ON, PWR-DET, Fil-DET, RGB,
CAN FD, SPI
Motor Driver
Support EZ5160, EZ2209, EZ2208, EZ2225, EZ2226,
EZ2130, EZ6609...
