Connection Description
USB Power Supply
After the BIGTREETECH MANTA E3EZ V1.0 has been powered, the Red light 3V3 will
light up, indicating power on. When using only USB to power the board, please insert the
jumper cap onto the VBUS.
Motor Voltage Selection
Select Motherboard Supply Voltage
Select Motor Supply Voltage
