3. Scope of delivery, transportation, storage, and installation
3.1 Unpacking, and checking equipment and scope of delivery
After unpacking, please check the unit and its optional accessories, if any, based on the delivery note for
completeness and for transportation damage. If transportation damage has occurred, immediately inform
the carrier or post office/parcel service.
Scope of delivery:
• Alarm Box 235 mm x 115 mm x 255 mm (W x H x D)
• Connection cable for alarm output (2-wire) 2 m with DIN-plug
(connection between Alarm Box AB 01 and telephone dialing device TWG 01)
• Connection cable RS422 15m
(connection between plug distributor and Alarm Box AB 01)
• Operating Manual Alarm Box AB 01, Art. No. 7001-0133
For disposal of the transport packing, see chap. 9.1.
3.2 Storage
Intermediate storage of the unit is possible in a closed and dry room. Observe the guidelines for
temporary decommissioning (chap. 9.2).
•
Permissible ambient temperature range during storage: -10°C to +60°C.
• Permissible ambient humidity during storage: max. 70 % r.H., non-condensing
If following storage in a cold location the unit is transferred to the installation site for start-up,
condensation may form. Wait at least one hour until the oven has attained ambient temperature and is
completely dry.
3.3 Location of installation and ambient conditions
Select a convenient place for the Alarm Box AB 01. The place of the installation should:
• be close to the APT-COM™ 3 computer and the plug distributor
• be rather concealed or inaccessible
Set up the Alarm Box AB 01on an even surface, free from vibration and in a well-ventilated, dry location.
CAUTION
Danger of overheating.
Damage to the unit.
∅ Do NOT set up units in non-ventilated recesses.
¾ Ensure sufficient ventilation for dispersal of the heat.
• Permissible ambient temperature range during operation: +18°C up to +40°C.
• Permissible ambient humidity during operation: 70 % r.H. max., non-condensing.
• Installation height: max. 2000 m above sea level.
Note that unauthorized persons may switch off the device or the audible alarm signal. We
recommend installation e.g., inside a distribution box.
