Binder AB 01 - Connection to APT-COM 3 DataControlSystem

AB 01 01/2009 page 13/26
4.2 Connection to the communication software APT-COM™ 3
DataControlSystem
Sample system APT-COM™ 3 DataControlSystem GLP Edition with monitoring software “WatchTool"
optionally installed on a second computer:
2
1
3
30
Measuring
computer
APT-COM 3
Serial computer
interface
COM1 or COM 2
RS-232
RS-422
Alarmbox AB 01
with installation of monitoring
software "Watch Tool" on the
same computer as APT-COM 3
CB
Alarm
Box
BD
ED
FD
KBF
Telephone
dialing device
APT-Line (E2)
Connection cable 15 m
A
rt. No. 5023-0036
Cable set
acc. to type of
interface converter
Interface converter W&T
Plug distributor expansible by
modules, Art. No. 8012-0295
...
Alarm Box AB 01
with installation of monitoring software
"Watch Tool" on a second computer
(monitoring computer)
Serial computer
interface
COM1 or COM 2
RS-232
RS-422
Cable set
acc. to type of
interface converter
Interface converter W&T
29
MK
Monitoring
computer
Watch Tool
Network connection
Ethernet
RS-422
Ethernet
RS-422
Alarm
Box
30
Telephone
dialing device
Figure 4: Sample system APT-COM™ 3 DataControlSystem GLP Edition
