2.2.2 Structural composition of BBS-DSC/BBS-SSC (Picture 9)
1. Control Panel 2. Power Socket
3. UV Lamp 4. LED Lamp
5. Front Window 6. Door knob
7.Work Table 8. Base Stand
9. Caster 10. Leveling Feet
Picture 9
2.2.3 Structure Introduction
1) Driving system of front window
Driving system consists of constant force spring and front window.
2) Air filtration system
Air filtration is the core system of laminar flow cabinet. It consists of blower and filter. The main
function of air filtration system is to transfer filtered air to work area, ensure the flow velocity, and
keep cleanness of work area.
3) UV lamp
The UV lamp located at the top of the work zone effectively disinfects the entire work zone by
emitting a wavelength of 253.7nm
4) LED lamp
Laminar flow cabinet is equipped with energy-saving LED LED lamp, which ensures the standard
requirement of average illumination is met
5) Control panel (Picture 10)
4
5
10
1
2
3
6
7
8
9
