Setting the Alarm Setpoint
This section will explain how to set the alarm setpoint. Remember,
when you wish the alarm function to be active you must make sure
the alarm switch on the front of the controller is on.
1. Push the “up” and “down” buttons at the same time for 3 seconds.
2. Now, go to “LEVL 2”. In ‘LEVL 2” navigate to “SP2.A”. Change this number to either
“DV.hi” (Deviation High) or “DV.Lo” (Deviation Low). This will determine whether the alarm
activates below or above the “SEt.2” (alarm setpoint).
3. In “LEVL 1” navigate to “SEt.2”. Adjust this number by holding the “*” button and using the
“up” or “down” buttons. Change this number to the desired alarm setpoint.
4. In “LEVL 1” navigate to “bnd.2”. This number will determine the range of the alarm setpoint.
The “bnd.2” number is a coarse adjustment, the number that you change this to will
not be the exact size of the band width. To set the alarm to activate as quickly as possible,
set the band to “0.1”. Increase the number to increase the range. Remember it is a coarse
adjustment.
5. Remember, if you want the alarm to have the ability to come on you must flip the “Alarm”
switch on the front panel.
21
Proox model 360
version 1.0
