Chapter 1: Introducon | 3
B560MX-E PRO | B560MH-E PRO
Chapter 1: Introducon
1�1 Before You Start
Thank you for choosing our product. Before you start installing the motherboard, please make
sure you follow the instrucons below:
•  Prepare a dry and stable working environment with sucient lighng.
•  Always disconnect the computer from power outlet before operaon.
•  Before you take the motherboard out from an-stac bag, ground yourself properly
by touching any safely grounded appliance, or use grounded wrist strap to remove the
stac charge.
•  Avoid touching the components on motherboard or the rear side of the board unless
necessary. Hold the board on the edge, do not try to bend or ex the board.
•  Do not leave any unfastened small parts inside the case aer installaon. Loose parts
will cause short circuits which may damage the equipment.
•  Keep the computer from dangerous area, such as heat source, humid air and water.
•  The operang temperatures of the computer should be 0 to 45 degrees Celsius.
•  To avoid injury, be careful of:
Sharp pins on headers and connectors
Rough edges and sharp corners on the chassis
Damage to wires that could cause a short circuit
1.2 Package Checklist
•  Serial ATA Cable x2
•  Rear I/O Panel for ATX Case x1
•  Quick Installaon Guide x1
•  Fully Setup Driver DVD x1
Note
»
  Thepackagecontentsmaybedierentduetothesalesregionormodelsinwhichitwassold.For
moreinformaonaboutthestandardpackageinyourregion,pleasecontactyourdealerorsales
representave.
