Biostar B560MX-E PRO User Manual

4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Support for 10th/ 11th Generaon Intel® Core™ i9/ i7/ i5/ i3 processors and Intel® Penum® processors/
Intel® Celeron® processors in the LGA1200 package
* Please refer to www.biostar.com.tw for CPU support list.
Chipset Intel® B560
Memory
Supports Dual Channel DDR4 2933/ 2800/ 2666/ 2400/ 2133
4x DDR4 DIMM Memory Slot, Max. Supports up to 128 GB Memory
Each DIMM supports non-ECC 4/8/16/32GB DDR4 module
* Please refer to www.biostar.com.tw for Memory support list.
Storage
-- Total supports 2x M.2 socket and 4x SATA III (6Gb/s) ports
4x SATA III Connector (6Gb/s) : Supports AHCI, RAID 0, 1, 5, 10 & Intel® Rapid Storage Technology
1x M.2 (M Key) Socket (M2_PCIEG4_64G_11TH_ONLY):
Supports M.2 Type 2280 SSD module
Supports PCI-E 4.0 x4 (64Gb/s) - NVMe/ AHCI SSD
Support 11th Gen processor only
1x M.2 (M Key) Socket (M2_PCIEG3_32G_SATA_RST1):
Supports M.2 Type 2242/ 2260/ 2280 SSD module
Supports PCI-E 3.0 x4 (32Gb/s) - NVMe/ AHCI SSD & SATA III (6Gb/s) SSD
Supports Intel® Optane Technology
* M.2 (M Key) Socket (M2_PCIEG4_64G_11TH_ONLY) support 11th Gen Rocket Lake-S CPU only.
LAN
Intel® I219V
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC897
7.1 Channels, High Denion Audio, Hi-Fi(Front)
USB
6x USB 3.2(Gen1) port (4 on rear I/Os and 2 via internal headers)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots
1x PCIe 3.0 x1 Slot
1x PCIe 4.0 x16 Slot (x16 mode)
1x PCIe 3.0 x16 Slot (x4 mode)
Rear I/Os
B560MX-E PRO:
2x WIFI Antenna Port
1x PS/2 Keyboard/ Mouse Port
1x VGA Port
1x DVI-D Port
1x HDMI Port
4x USB 3.2 (Gen1) port
2x USB 2.0 port
1x LAN port
3x Audio Jack
B560MH-E PRO:
2x WIFI Antenna Port
1x PS/2 Keyboard/ Mouse Port
1x VGA Port
1x HDMI Port
4x USB 3.2 (Gen1) port
2x USB 2.0 port
1x LAN port
3x Audio Jack

»
ConnuedonNextPage

Biostar B560MX-E PRO Specifications

General

PCI Express x16 slots	2
PCI Express x1 (Gen 3.x) slots	1
Memory channels	Dual-channel
Memory slots type	DIMM
Unbuffered memory	Yes
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2666, 2933, 3200, 3600, 3733, 3800, 3866 MHz
Audio chip	Realtek ALC897
Component for	PC
Motherboard chipset	Intel B560
PC health monitoring	FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard chipset family	Intel
Windows operating systems supported	Windows 10 x64
Processor socket	LGA 1200 (Socket H5)
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Wi-Fi	No
LAN controller	Realtek RTL8111H
Ethernet interface type	Gigabit Ethernet
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Cables included	SATA
Bundled software	BullGuard
BIOS type	-
DirectX version	12.0
Parallel processing technology support	Not supported
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	244 mm
