Component Index

* optional

◎ only support with South Bridge VT8237

A. ATX Power Connector (JATXPWR1) N. Wake On LAN Header (JWOL1)

B. Power Source Selection for Keyboard O. Floppy Disk Connector (FDD1)

and Mouse (JKBV1) P. Front Panel Connector (JPANEL1)

C. Power Source Selection for USB Q. System FAN Header (JSFAN1)

(JUSBV3) R. Audio DJ (JDJ1)

D. Back Panel Connector S.

Serial ATA Connector (JSATA1-2) ◎

◎◎

◎

E. Case Open Connector (JCI1) T.

Front USB Header (JUSB1) ◎

◎◎

◎

F. Front 1394 Header(J1394B1) * U. Front USB Header (JUSB2)

G. Accelerated Graphics Port Slot (AGP1) V. Power Source Selection for USB

H. PCI BUS Slots (PCI1-3) (JUSBV2)

I. Front Audio Header (JF_AUDIO1) W. Clear CMOS Function (JCMOS1)

J. Digital Audio Connector (JSPDIF1) X. IDE Connectors (IDE1-2)

K. CD-ROM Audio-In Header (JCDIN1) Y. DDR Modules (DDR1-2)

L. Communication Network Riser Slot Z. CPU Fan Connector (JCFAN1)

(CNR1) A1 Frequency Selection (JCLK1)

M. CNR Codec/ Onboard Selection B1 Power Source Selection for USB

(JCODECSEL1) (JUSBV1)
