3
English
M7VIZ Features
A. Hardware
CPU
Provides Socket A.
Supports single AMD
®
Athlon/ Duron Family processor.
Front Side Bus at 200/266/333 MHz.
Chipset
North Bridge: VIA KM400.
South Bridge: VIA VT8235CE/ VT8237.(optional)
Main Memory
Supports up to 2 DDR devices.
Supports 200/266/333 MHz (without ECC) DDR devices.
Maximum memory size is 2GB.
Super I/O
Chip: Winbond W83697HF.
Slots
Three 32-bit PCI bus master slots.
One CNR slot. (only Type B)
One AGP 8X slot.
On Board IDE
Supports four IDE disk drives.
Supports PIO Mode 4, Master Mode and Ultra DMA 33/66/100/133 Bus Master
Mode.
LAN
Chip: VIA VT6103.
Supports 10 Mb/s and 100 Mb/s auto-negotiation
Half/Full duplex capability.
IEEE 1394 Chip (optional)
Chip: VIA VT6307.
Supports 2 IEEE 1394 ports.
Detects connected device types and automatically cofigure data speed to 100, 200
or 400 Mbps.
On Board AC’97 Sound Codec
Chip: CMI9739A.
Compliant with AC’97 specification.
