Chapter 2 BIOS Setup
2-19
Onboard FDD Controller
Select Enabled, if your system has a floppy disk controller (FDC) installed on the
system board, and if you wish to use it. If install and FDC or the system has no
floppy drive, select Disabled in this field.
The Choices: Enabled (default), Disabled.
Onboard Serial Port
Select an address and corresponding interrupt for the first and second serial ports.
The Choices: 3F8/IRQ4
(default), Disabled, Auto, 2F8/IRQ3, 3E8/
IRQ4, 2E8 / IRQ3.
IrDA Port
Select an address and corresponding interrupt for the first and second serial ports.
The Choices: Disabled (default), Auto, 3F8/IRQ4, 2F8/IRQ3, 3E8/
IRQ4, 2E8 / IRQ3.
UART 2 Mode
This item allows you to determine which Infrared (IR) function of the onboard I/O
chip you wish to use.
The Choices: HPSIR (default), ASKIR.
IR Function Duplex
This item allows you to determine which Infrared (IR) function of onboard I/O
chip.
The Choices: Half (default), Full.
TX, RX inverting enable
This item allows you to determine the active of Rx, Tx.
The Choices: No, No
No, Yes (default)
Yes, No
Yes, Yes
Onboard Parallel Port
This item allows you to determine access onboard parallel port controller with
which I/O address.
The Choices: Disabled, 3BC/IRQ0, 378/IRQ7 (default), 278/IRQ5.
