Biostar M7VKQ User Manual

Chapter 2 BIOS Setup
2-20
Onboard Parallel Mode
Select an operating mode for the onboard parallel (printer) port. Normal EPP
(Extended Parallel Port) ECP (Extended Capabilities Port) ECP+EPP PC AT
parallel port Bidirectional Port Fast, buffered port Fast, buffered, Bidirectional Port.
Select Normal unless you are certain your hardware and software both support EPP
or ECP mode.
The Choice: Normal (default), EPP, ECP, ECP/EPP.
ECP Mode Use DMA
Select a DMA channel for the parallel port for use during ECP mode.
The Choice: 3(default), 1.
Parallel Port EPP Type
Select a DMA Channel for the port.
The Choice: EPP1.9 (default), EPP1.7.
Onboard Legacy Audio
This field controls the onboard legency audio.
The Choices: Enabled (default), Disabled.
Sound Blaster
Hardware SoundBlaster Pro for Windows DOS box and real-mode DOS legacy
compatibility.
The Choices: Disabled (default), Enabled.
SB I/O Base Address
Change the SoundBlaster Pro Base I/O Address settings.
The Choices: 220H (default), 240H, 260H, 280H.
SB IRQ Select
Change the SoundBlaster Pro interrupt signal.
The Choices: IRQ5 (default), IRQ7, IRQ9, IRQ10.
