Biostar TPower I45 User Manual

TPower I45
27
CHAPTER 6: T-POWER BIOS & SOFTWARE
6.1 T-P
OWER BIOS
T-Power BIOS Features
Overclocking Navigator Engine (O.N.E.)
Memory Integration Test (M.I.T., under Overclock Navigator Engine)
BIO-Flasher: Update BIOS file from USB Flash Drive or FDD
Self Recovery System (S.R.S)
Smart Fan Function
CMOS Reloading Program
A. Overclocking Navigator Engine (O.N.E.)
ONE provides two powerful overclocking engines: MOS and AOS for both
Elite and Casual overclockers.
BIOS SETUP UTILITY
Main Advanced
PCIPnP Boot
Chipset O.N.E
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Over-Clocking Navigator setting
WARNING: Setting wrong values in below sections
may cause system to malfunction.
=========== Automate OverClock System ===========
============ Manual OverClock System ============
Over-Clocking Navigator [Normal]
Memory Test [Disabled]
Auto OverClock System [V6-Tech Engine]
Intel(R) SpeedStep(tm) tech [Enabled]
Ratio CMOS Setting [ x9.0]
CPU Frequency Setting [333]
FSB(Bsel) To NorthBridge Latch [Auto]
DRAM Frequency [Auto]
DDR2 Enhanced Mode [Auto]
> DRAM Timing Configuration
> Clock Gen Configuration
> Voltage Configuration
Exit
Options
Normal
Automate OverClock
Manual OverClock
!! WARNING !!
For better system performance, the BIOS firmware is being
continuously updated. The BIOS information described below in
this manual is for your reference only and the actual BIOS
information and settings on board may be different from this
manual. For further information of setting up the BIOS, please
refer to the BIOS Manual in the Setu
p
CD.

Biostar TPower I45 Specifications

General

Number of memory slots	4
Maximum internal memory	16 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron Dual-Core, Intel Pentium Dual-Core
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of SATA connectors	6
PS/2 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	-
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC888S
Motherboard form factor	ATX
Compatible operating systems	Windows 2000/XP/Vista
RAID levels	0, 1, 5, 10
LAN controller	Realtek RTL8111C
Networking features	Gigabit Ethernet
