1.3 MOTHERBOARD FEATURES
SPEC
CPU
LGA 775
Intel Core2Duo / Core2Quad /
Pent iu m Dual-Core / C eleron Dual-Core /
Celeron 4xx processor
Supports Execute Disab le B it / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization Technology
FSB Support 800 / 1066 / 1333 / 1600 MHz
Chipset
Intel P45
Intel ICH1 0R
Super I/O
Fintek F71887F
Provides the most commonly used legacy
Super I/O functionality.
Low Pin Count Interface
Environment Control in it iatives,
Hardware Monitor Controller
Fan Speed Contro ller
ITE's "S mart Guardian" funct ion
Main
Memory
DIMM Slots x 4
Each DIMM supports 256MB / 512MB /
1GB / 2GB DDR2
Max Memory Capicity 8GB
Dual Channel Mode DDR2 memory module
Supports DDR2 1066 / 800 / 667
Registered D IMM and ECC D IMM is not supported
IDE Marvell 88SE6121
Ultra DMA 33 / 66 / 100 / 133 Bus Master Mode
supports PIO Mode 0~4
SATA II ICH10R
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 s pecif icat ion co mp liant.
RAID 0 / 1 / 5 / 1+0 support
eSATA Marvell 88SE6121
Data transfer rates up to 3 Gb/s.
SATA Version 2.0 s pecif icat ion co mp liant.
Port-Multiplier/RAID 0,1 support
LAN Realtek RTL 8111C
10 / 100 Mb/s / 1Gb/s auto negotiation
Half / Full duplex capability
Sound
Codec
ALC888S
7.1 channels audio out
High Definition Audio
PCI slot x2 Supports PCI expansion cards
PCI Express Gen2 x16 slot (x16/x8) x1 Supports PCI-E Gen2 x16 expansion cards
PCI Express Gen2 x16 slot (x8) x1 Supports PCI-E Gen2 x16 expansion cards
Slots
PCI Express x1 slot x2 Supports PCI-E x1 expansion cards
Floppy connector x1 Each connector supports 2 Floppy drives
Serial port Connector x1 Connects to RS-232 Port
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x6 Each connector supports 1 SATA devices
On Board
Connector
Front Panel Connector x1 Supports front panel facilities

Biostar TPower I45 Specifications

General

Number of memory slots	4
Maximum internal memory	16 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron Dual-Core, Intel Pentium Dual-Core
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of SATA connectors	6
PS/2 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	-
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC888S
Motherboard form factor	ATX
Compatible operating systems	Windows 2000/XP/Vista
RAID levels	0, 1, 5, 10
LAN controller	Realtek RTL8111C
Networking features	Gigabit Ethernet
