Biostar TPower I45 - Motherboard Layout

Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
BIOS
FDD1
PEX16_1
PCI1
JATXPWR1
JCFAN1
CO DE C
JSFAN1
BAT1
LGA775
CPU1
JKBMS1
JUSB2
JRJ45USB1
IDE1
DDR2_A1 DDR2_A2 DDR2_B1 DDR2_B2
IDE
Super
I/O
JUSB1
RSTSW2
PEX1_1
PCI2
JCDIN1
JUSB4 JUSB3 JPANEL 1
PWRSW 1
JU SB5
Intel
P45
Intel
ICH10R
JAUDIO1
LAN
PEX1_2
JUSBV1
JUSBV2
PEX16 _2
JPE1 JPE3 JPE5 JPE7
JPE2 JPE4 JPE6 JPE8
ESATAX1
J1
JNFAN1
JSPDIF_OUT2
JSPDIF_OUT1
JAUDIOF1
JSPDIF_IN1
JCOM1
JCMOS1
JPE9
JATXPWR2
SATA1
SATA2
SATA3
Note: represents the 1■
st
pin.
