Biostar TPower I45 User Manual

Motherboard Manual
38
EX: This means V9 engine is activated.
<V3/V6/V9/V12/V15 Engine>
By clicking ,
the utility would over-clock the system
with certain fixed percentage. When the
V3/V6/V9/V12/V15 engine is activated,
you will see the green light bar on the left
rising to the top of the button.
This function is recommended for
any inexperienced users.
<Save/Load/Delete Setting>
You can save current setting to a file by clicking , then a dialog as bellow
will show.
Enter file name and click “Save”, and then the current setting would be saved.
To load a previously saved file, click on , and the saved files would show
as bellow. Click on the file name and then choose “Yes” to load the setting.
To delete a previously saved file; load the setting first Æ click on (for VGA
setting is ) Æ choose “Yes”, and the setting file will be deleted.
(Be aware of that VGA setting for V-Ranger powered VGA card must be
saved/loaded/deleted respectively.)
Over-clock is an optional process but not a “must-do” process, and actual over-clock
result varies by every individual PC system. Therefore, we will neither guarantee any
over-clock performance nor be responsible for any system damage that may be caused
by over-clock. Any values or performance shown above are for reference only.

Biostar TPower I45 Specifications

General

Number of memory slots	4
Maximum internal memory	16 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron Dual-Core, Intel Pentium Dual-Core
USB 2.0 connectors	3
S/PDIF out connector	Yes
Number of SATA connectors	6
PS/2 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Parallel ports quantity	-
Ethernet LAN (RJ-45) ports	1
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC888S
Motherboard form factor	ATX
Compatible operating systems	Windows 2000/XP/Vista
RAID levels	0, 1, 5, 10
LAN controller	Realtek RTL8111C
Networking features	Gigabit Ethernet
