Specifications
15
Crest Factor
RF Power Range 0.15 to 150 W average, 4 W
minimum peak
Measurement Uncert. Linear sum of peak and average
power uncertainty
Complementary Cumulative Distribution Function (CCDF)
Measurement Range
1
1 Duty Cycle and CCDF read out dependent on display
method.
0.1 to 100%
Measurement Uncert. ± 2%
Threshold Level Range 2 to 400 W peak
Level Set Accuracy As peak power uncert. + 2%
Physical and Environmental Specifications
Temp, Operating –10 to +50 °C (+14 to +122 °F)
Temp, Storage –40 to +80 °C (–40 to +176 °F)
Mechanical Shock
and V
ibration
MIL-PRF-28800F class 3
Humidity, Max 95% (non-condensing)
Altitude, Max 15,000 ft. (4,500 m)
Dimensions,
Nominal
4.75” x 4.6” x 1.3” (121 x 117 x 33 mm)
Weight, Max 1.2 lb. (0.55 kg)
EMC EMC Directive (2004/108/EC)
European Standard: EN 61326—
Electrical Equipment for measurement,
control and laboratory use; EMC
Requirements
Test Spec (for radiated immunity): EN
61000-4-3—T
esting and measurement
techniques - 10V/meter
