Wideband Power Sensors
32
5019D Specifications
Sensor Characteristics
Frequency Range 25 MHz to 1.0 GHz
RF Power Range 100 mW to 100 W average,
2.6 to 260 W peak
Maximum Power See
Figure 20 on page 34
.
Impedance, Nominal 50 ohms
Insertion Loss, Max:
25 – 1000 MHz
0.05 dB
Input VSWR, Max:
25 – 1000 MHz
1.05
Directivity, Min:
25 – 100 MHz
100 – 1000 MHz
28 dB
30 dB
RF Connectors N Female
Interface:
DPM
PC Serial Port
PC USB Port
Male DB-9, RS-232, 9600 Baud, no
parity
, 8 data bits, 1 stop bit
Female DB-9, EIA-232, 9600 Baud,
no parity
, 8 data bits, 1 stop bit
USB 1.1 interface
Power Supply:
DPM
USB Port
DC Connector
From host instrument via cable
less than one low-power USB load
7 – 18 Vdc, < 100 mA
Data Logging In VPM software
Average Power
RF Power Range 100 mW – 100 W
Peak/Average Ratio, Max 12 dB
Measurement Uncert. ± (4% of reading + 166 mW)
1
1 Above 35 °C or below 15 °C add 3%
