Wideband Power Sensors
22
5017D/5017D-AV Specifications
Sensor Characteristics
Frequency Range
5017D
5017D–AV
25 MHz to 1 GHz
100 MHz to 1.3 GHz
RF Power Range
1
500 mW to 500 W average, 13.3W to
1300 W peak
1
1 Derate maximum average power rating from 500W at 300MHz to
100W at 1GHz using a straight line on a log-log scale.
Maximum Power See
Figure 14 on page 24
.
Impedance, Nominal 50 ohms
Insertion Loss, Max:
5017D: 25 – 50 MHz
5017D–AV:
100 – 1000 MHz
1000 – 1300 MHz
0.05 dB
0.05 dB
0.1 dB
Input VSWR, Max:
5017D: 25 – 1000 MHz
5017D–AV: 100 – 1300 MHz
1.05
1.05
Directivity, Min:
5017D:
25 – 50 MHz
51 – 1000 MHz
5017D-AV:
100 – 1300 MHz
29 dB
30 dB
30 dB
RF Connectors N Female
Interface:
DPM
PC Serial Port
PC USB Port
Male DB-9, RS-232, 9600 Baud, no
parity
, 8 data bits, 1 stop bit
Female DB-9, EIA-232, 9600 Baud,
no parity
, 8 data bits, 1 stop bit
USB 1.1 interface
Power Supply:
DPM
USB Port
DC Connector
From host instrument via cable
less than one low-power USB load
7 – 18 Vdc, < 100 mA
Data Logging In VPM software
