BIRD 5012D - 5016 D Specifications; Sensor Characteristics

Specifications
17
5016D Specifications
Sensor Characteristics
Frequency Range 350 MHz to 4 GHz
RF Power Range 25 mW to 25 W Average, 1W to 60 W
peak
Maximum Power See
Figure 11 on page 19 .
Impedance, Nominal 50 ohms
Insertion Loss, Max:
0.35 – 1 GHz
1 – 4 GHz
0.05 dB
0.1 dB
Input VSWR, Max:
0.35 – 2.5 GHz
2.5 – 4 GHz
1.05
1.10
Directivity, Min:
0.35 – 3 GHz
3 – 4 GHz
30 dB
28 dB
RF Connectors N Female
Interface:
DPM
PC Serial Port
PC USB Port
Male DB-9, RS-232, 9600 Baud, no
parity
, 8 data bits, 1 stop bit
Female DB-9, EIA-232, 9600 Baud,
no parity
, 8 data bits, 1 stop bit
USB 1.1 interface
Power Supply:
DPM
USB Port
DC Connector
From host instrument via cable
less than one low-power USB load
7 – 18 Vdc, < 100 mA
Data Logging In VPM software
Average Power
RF Power Range 25 mW to 25 W
Peak/Average Ratio, Max 12 dB
Measurement Uncert. ± (4% of reading + 8 mW)
1
1 Above 35 °C or below 15 °C add 3%
