BIRO F1000N - Page 27

24
Description
Item No.
F9321500
Plastic knob only
F93M0059
Guide pin
F93M0060
Bracket, paper pusher
F93M0061
Screw, cam adjusting
F93M0062
Cam
F93M0063
Release lever
F93M0067
Pin, release lever
F93M0068
Spring
Fig No.
1
2
3
4
5
6
7
8
9
11
F93M0070
Support, Right
F93M0076
Bushing, JFM-0810-07
DescriptionItem No.
F93M0084
Complete Bracket Assembly
F93M0109
Locking collar
GVT085
Hex nut, M5-0.8, SS
GVT125
Flat washer, M5, SS
GVT192
Hex head screw, M5-0.8 x 10, SS
GVT435
Set screw cup pt, M5-0.8 x 5, SS
Fig No.
13
14
15
16
17
18
19
12
F93M0065
Locking pin
GVT111
Nylok nut, M5-0.8, SS
PAPER PUSHER BRACKET
10
F93M0069
Support, Left
1
2
4
5
6
3
7
8
9
10
11
12
13 - ASSEMBLY
14
12
15
15
16
16
17
17
18
18
19
F93M0084
