3 ANTSPACE HK3 Container Water Cooling System Composition and
Working Principle
3.1 System Overview
The container Water cooling system aims to continuously provide cooling Water that meets the
pressure, temperature, and flow requirements for the heat dissipation unit of the internal high
computing power server, ensuring a good working environment for the load.
There are three types of heat dissipation options for container Water cooling systems: evaporative
cooling (dry wet combined dry tower), water-water heat exchange (plate exchange component), and
forced air cooling (dry tower). The internal cooling medium can be selected according to the local
environmental temperature, such as suitable antifreeze, deionized water, or pure water.
3.2 System Composition
Table 3-1 Main components of container Water cooling system
Sub system
Function
Main components
Pumping
station
Transport and monitor the cooling
Water status to maintain stable system
operation
Centrifugal pumps, expansion tanks,
sensors, valves, exhaust valves,
filters, pipelines, and other related
accessories
Control cabinet
Control the operation of various
components in the pump station, read
the numerical display of each sensor,
and upload it
Circuit breakers, intermediate relay,
PLC, switch power supply, touch
screen, and other related accessories
Network and
distribution
system
Distribute network and power for high
computing power servers
Circuit breakers, aviation plugs,
cables, switches, and other related
accessories
Mainfold
system
Flow distribution and transportation
Main fold, elbows, hoses, chucks,
valves, and other related accessories
Accessories
Supporting components and spare
accessories required for the use of
container Water cooling system
Screws, miniature circuit breakers,
aviation plugs, clamps, rubber hoses
and other related accessories
Dry wet tower
(optional)
Transfer heat from the load to the
atmosphere
Spray pumps, coolers, air inlet
grilles, fans, and other related
accessories
Dry tower
(optional)
Transfer heat from the load to the
atmosphere
Stainless steel heat exchanger
components, valves, pressure
gauges, and other related accessories
Plate heat
exchanger
component
(optional)
Transfer heat from the load to the cold
side water
Plate heat exchangers, sensors,
valves, and other related accessories
