ANTSPACE HK3 Water cooling container & Dry-Wet Tower Product Manual
69
Inspection requirements: Check the system alarm points and follow the instructions for
troubleshooting.
Inspection method: visual inspection and on-demand testing.
9.3 Regular Inspections
1) Maintenance of Filters
The system is divided into internal circulation and external circulation, with the internal
circulation medium being coolant and the external circulation medium being tap water. The system
has set up a filter to filter the internal and external circulation, and the filter needs to be cleaned after
the system has been running for a period of time.
The filter is divided into three parts, and the corresponding cleaning time requirements are as
follows:
a) Cooling tower spray pump suction filter, cleaning cycle is once a month.
b) The filter in the internal circulation pipeline of the pump unit Water supply system has a cleaning
cycle of once a month (or as needed).
c) The Y-shaped filter in the internal circulation pipeline of the pump unit replenishment system
has a cleaning cycle of once every six months (or as needed).
The cleaning method is to wash with clean water and rinse thoroughly before use.
Operation steps:
a) Cut off the main power supply of the equipment.
b) Referring to Figure 9-1, close the maintenance butterfly valves in the system, open the drain ball
valve below the pipeline filter component, and drain the local Water in the pipeline.
c) After finding the position of the filter, open the manual exhaust valve and manual drain valve,
remove the clamp connection, and take out the pipeline filter element from the handle.
