brackets from the wooden box. Then, take out the flange sealing gasket, chuck gasket,
connecting bolt (M16×75), high-pressure clamps (ISO 114.3 and ISO 141.3) and U-shaped
clamp components and other accessories.
b) Find two water supply and return pipelines (with an outer diameter of 114.3) in the container,
labeled as BTMU XX WBGL03 (with filter Z01) and BTMU XX WBGL04. Connect the
pipelines to the two water supply and return ports with high-pressure clamps (ISO
114.3/304/PN16) in combination with the chuck sealing gasket (ISO 114.3). It should be noted
that the sealing gasket should not be damaged, worn, or deformed. External pipeline 03
(BTMUXX WBGL03) is connected to the inlet of the container system on the upper side, and
BTMUXX WBGL04 is connected to the outlet of the container system on the lower side. After
the connection is completed, fix them with a pipeline bracket and a DN100 U-shaped clamp.
c) Connect the above pipelines according to the requirements in Figure 6-4. There are 10
connections in total: 6 flange connections, 8 single connection points, and 1 DN125 sealing
gasket is required for each connection; 4 chuck connections, 1 connection point at a single
location, and 1 ISO 141.3 chuck sealing gasket is required for each connection. It should be
noted that the sealing gasket should not be damaged, worn, or deformed.
2) Fixed pipelines and external pipeline brackets
After connecting the intermediate pipeline, it is necessary to fix the pipeline and external
pipeline bracket:
a) Fix the external pipeline bracket.
The pipeline needs to be tightly attached to the bracket for fastening. The external pipeline
bracket is fixed to the ground using expansion screws (M12 * 80), and the ground needs to be
drilled in advance using an electric drill.
b) Use U-shaped pipeline clamps (DN125/M12/304) to secure the pipeline to the external pipeline
bracket.
c) Check if the connection points are loose and mark all threaded connection points with a line
(black and blue double marking is recommended).
