ANTSPACE HK3 Water cooling container & Dry-Wet Tower Product Manual
44
Table 7-1 Functional description of circuit breakers in the main control cabinet
SN
Name
Starting point
Direction
End point
1
QFWCU
Power incoming XT1
L1,L2,L3
→
XD11，XD12，XD13，L1，
L2，L3
2
QFKR1
XD11 L1
→
Power monitor L1
3
QFKR2
XD12 L2
→
Power monitor L2
4
QFKR3
XD13 L3
→
Power monitor L3
5
QFHL1
XT1 L1
→
Power indicator light (white)
6
QFHL2
XD11 L1
→
Closing indicator light (green)
7
QFD1
L1,N
→
Backup power supply
8
QFaSW
XD11 L1
→
Distribution cabinet switch power
supply
9
QFbSW
XD11 L1
→
Distribution cabinet switch power
supply
10
QFVF01
XD11,XD12,XD13
L1,L2,L3
→
Main pump frequency converter
R, S, T
11
-QFVF02
XD11,XD12,XD13
L1,L2,L3
→
Cold tower fan frequency
converter R, S, T
12
-QFG01
Cold tower fan frequency
converter U, V, W
→
Cooling tower fan front thermal
relay - FRG01 1,3,5
13
-QFG02
Cold tower fan frequency
converter U, V, W
→
Cooling tower fan front thermal
relay - FRG02 1,3,5
14
-QFG03
Cold tower fan frequency
converter U, V, W
→
Cooling tower fan front thermal
relay - FRG03 1,3,5
15
-QFVF03
XD11,XD12,XD13
L1,L2,L3
→
Cold tower spray pump frequency
converter R, S, T
16
QFCTMF
EV_L1+
→
Power supply 24V+
17
QFV1
EV_L+
→
KAKV102，KAGV102
18
QFV08
EV_L+
→
V008 power supply+
19
QFP1
XD13 L3
→
PLC power supply P1, pin 2
20
QFPZ1
PLC power supply P1, pin
5
→
P1_L+
21
QFP2
L1.4
→
P2 SDR-480-24 pin L
22
QFPZ2
P2 SDR-480-24 pin V+
→
Container lighting RCT4D
23
QFRDC
P2 SDR-480-24 pin V+
→
Distribution cabinet fan
24
QFMF
P2 SDR-480-24 pin V+
→
Cabinet radiator
25
QFP3
L1.4
→
SDR-75-12V P3 pin L
26
QFPZ3
SDR-75-12V P3 pin V+
→
Face recognition power supply,
