BIXOLON BCD-2000 User Manual

Rev. 1.02
- 12 -
BCD-2000
5. Features
5-1 Swivel
• This device can be swiveled freely. Please follow the instructions below to avoid damage or
malfunction when installing the device. To change the direction of the display after
installation, follow the instructions provided below.
(a)
(b)
(c)
* (a) Lower the body to the direction of the arrow. Spin the Nut Holder so the body goes down.
(Refer to the OPEN/CLOSE indications on the product.)
* (b) Swivel the body to the angle you want.
* (c) After adjusting the angle, tighten the Nut Holder. (Keep the body from swiveling when
moving it up and down.) Adjust the height of the body and tighten the Nut Holder.
Caution or
Warning
- Do not turn the body more than once in the same direction.
(The body can be turned indefinitely.)
- Do not over-tighten the Nut Holder as it can cause damage.
Please tighten so that the body does not move.
Pole Adjustable Ball
Nut Holder
Pole-Main
