BIXOLON BCD-2000 - BCD-2000 Pass Through Connection Mode

Rev. 1.02
- 8 -
BCD-2000
3-2 Pass Through
• Data transmits through Host(PC) → Display → Printer.
Item
Display-Serial
Standard
Model
BCD-2000DS
Standard
Board
Specifications
Power
(Optional)
24V, 2.5A 24V, 1.5A
Cable Types
(Optional)
Serial Cable 9PM to 25PF
Power Cable 3P to 3P
Power Cable 3P to 2P
Caution or Warning
- Please only use the genuine optional accessories.
