BIXOLON BCD-2000 User Manual

Rev. 1.02
- 7 -
BCD-2000
3. Initial Settings & Options (Serial)
3-1 Direct Connection
• Connected to the Display directly without passing through the board.
Item
Display-Serial
Standard
Model
BCD-2000N BCD-2000A
How to
Connect a
Power Cable
to the Serial
Cable
Connect an SMPS to the Serial Cable Jack
Voltage Used: 24V (2pin)
BCD-2000N+SMPS
Caution or Warning
- The above image may be different from the actual items.
