BIXOLON BCD-2000 - Tilting Mechanism for BCD-2000 Display Adjustment

Rev. 1.02
- 13 -
BCD-2000
5-2 Tilting
• The device can be tilted to the degree you want.
Please follow the instructions below to avoid damage or malfunction when installing the
device. It can be tilted up to 13° to each side with 4 levels and 5 positions. (Tilt: max. 52°)
Caution or Warning
- Do not tilt over the limit as it can cause damage.
Center Line
Center Line
