7-3 VMSM (Virtual Memory Switch Manager)
• Other than DIP switch settings, you can change the following settings using VMSM software.
The following settings apply when powered on and are executed by the initialization
command.
1) MSW 1 (BCD Common Setting)
Memory
S/W
Function
Default
Content to be set
Range to be set
1
Character code table
Selection
n=0
Page 0 is
selected
[BCD-2000]
0,17,18,20,27,31
[BCD-2000K]
0,1,2,3,4,5,14,15,16,
17,18,19,20,21,25,
26,27,28,29,30,31,32,
33,36,38,40,41,49,50,51
2
International character
set selection
n=0
U.S.A is selected
0-15
3
Selection of the
peripheral devices
n=2
Display is
selected
1-3
4
Cursor display
n=1
Cursor On
0, 1
5 ~ 7
Reserved
-
-
-
8
Sleep mode selection
n=0
Sleep mode off
0, 1
2) MSW 2 (BCD-2000 Setting)
Memory
S/W
Function
Default
Content to be set
Range to be set
1
Handshaking(BCD-2000)
n=0
DTR/DSR
0: DTR/DSR
1: Xon/Xoff
2
BCD Mode Selection
n=0
BCD-2000
0: BCD-2000
(8x16)
1: BCD-2000K
(9x17)
3 ~ 8
Reserved
n=0
-
-
3) MSW 3 (BCD-3000 Setting)
Memory
S/W
Function
Default
Content to be set
Range to be set
1 ~ 8
Reserved
n=0
-
-
4) MSW 4 (Display Position Setting)
Memory
S/W
Function
Default
Content to be set
Range to be set
1
Set horizontal row
BCD-2000: n = 4
BCD-2000K: n = 2
BCD-3000: n = 2
3-47.Character & Line Position
Reference for command
2
Max character
number
BCD-2000: n = 30
BCD-2000K: n = 20
BCD-3000: n = 20
3
Horizontal start
position of the first
character
BCD-2000: n = 0
BCD-2000K: n = 11
BCD-3000: n = 0
