8. Power Control
• The base board is located inside the base unit.
Remove the PCB cover by pressing the hook on the base unit as shown in the image below.
Caution or Warning
- Close the PCB cover before operation.
* Base Board
CN1
J2
J1
CN2
Jumper 1 (JP1) -
Power
Jumper 2 (JP2)-
Communication Cable
