BIXOLON SPP-L3000 - Interface Cable Connection

Ver. 1.00
- 30 -
SPP-L3000
6-2 Interface Cable Connection
1) Open the Interface Cap ①.
2) Connect the external communication
cable ② to the cable connector of the
printer.
3) Connect the interface cable to the USB
port of the device (PDAs, PCs, etc.).
NOTE
The interface cable that can be connected to
the printer is Serial/USB cable provided by
BIXOLON(optional) or mini 5-pin cable
supporting USB2.0.
①
②
